手板制作到检验设计的步骤
来源：http://dcjzl.com作者：哈希28单双发布时间：2023-06-03
手板模型在工厂中被广泛使用，开模前可以根据产品的图片或结构图，使用手板模型进行验证，避免造成损失。从制作到后期量产有几个阶段，每个阶段都缺一不可。下面就来了解一下从济南手板制作到后期量产的步骤。
Handboard models are widely used in factories, and can be verified based on product images or structural diagrams before mold opening to avoid losses. There are several stages from production to mass production, and each stage is indispensable. Let's take a look at the steps from Jinan hand board production to later mass production.
在开发和设计新产品时，设计师需要会先定位市场。根据公司的发展规划，结合市场定位，选择适合自己的新产品。确定新产品方案后，使用各种操作软件设计出所需的图纸，图纸可以多种格式保存，利于多方位参考在后期产品的样机打样中。
When developing and designing new products, designers need to first position themselves in the market. Based on the company's development plan and market positioning, choose a suitable new product for oneself. After determining the new product plan, use various operating software to design the required drawings. The drawings can be saved in multiple formats, which is conducive to multi-directional reference in the later product prototype proofing.
设计好新产品的图纸后，就是进行手板制作，以检验设计的可行性。手板的制作过程分为四个过程，准备工作、设计阶段、加工阶段和后处理阶段。这里的每个阶段都是环环相扣的，只要一个阶段没有做好，就会影响到下一阶段。
After designing the drawings for the new product, it is time to make a prototype to verify the feasibility of the design. The production process of a hand board is divided into four stages: preparation, design, processing, and post-processing. Each stage here is interconnected, and if one stage is not done well, it will affect the next stage.
部分零件在成型时有特殊要求，还需要使用温流道、气辅成型、氮气瓶等技术。一般大型冲压手板模型，需要考虑机床是否有下料布置，甚是否有润滑油、多工位级进等，除了冲压吨位外，还需要考虑冲压次，送料设备，机床和原型模型保护设备。
Some parts have special requirements during molding and require the use of technologies such as warm runner, gas assisted molding, and nitrogen bottles. For general large-scale stamping hand board models, it is necessary to consider whether the machine tool has a cutting arrangement, and even whether there is lubricating oil, multi-station progressive, etc. In addition to the stamping tonnage, it is also necessary to consider the stamping frequency, feeding equipment, machine tool, and prototype model protection equipment.
手板制作步骤结束后，设计师将对手板进行测试。如果测试结果不理想，设计师需要结合数据对图纸进行修改，然后重新验证。如果外观和性能没有问题，就会进入下一步，小批量生产。
After the steps of making the hand board are completed, the designer will test the hand board. If the test results are not satisfactory, the designer needs to modify the drawings based on the data and then revalidate them. If there are no issues with appearance and performance, we will proceed to the next step, small-scale production.
小批量生产的目的是看新产品有没有新的缺点。如果没有新的缺陷，就可以准备模具了。开模后就可以正式生产了，正式生产后产品才能投放市场，企业才能开始正式盈利。更多相关事项就来我们网站http://dcjzl.com咨询了解！
The purpose of small-scale production is to see if new products have new shortcomings. If there are no new defects, the mold can be prepared. After the mold is opened, it can be officially produced. Only after formal production can the product be put on the market and the enterprise begin to make profits. For more related matters, come to our website http://dcjzl.com Consultation and understanding!
