Programming: Handboard processing requires designing product drawings (3D, 2D) first, and programming based on 3D drawings. This step involves professional engineers programming, with some complex parts requiring disassembly programming. Then input the compiled program into a CNC or 3D printer to create a shape.

成型：成型有CNC加工和3D打印。

Forming: Forming includes CNC processing and 3D printing.

CNC电脑锣加工是根据编好的程序加工，需要的操机师傅作业，按照程序裁切材料大小，然后找原点按程序走刀，一般是先走开粗刀再刀精密刀在到光刀。手板很多零件是需要加工几个面的，就需要填充石膏翻面加工。填石膏是省去制造夹具成本。加工好的产品再把石膏敲除清洗。

CNC computer gongs are processed according to a programmed program, requiring professional machine operators to cut material sizes according to the program, and then find the origin and follow the program to move the knife. Generally, the coarse knife is removed first, and then the precision knife is cut to the smooth knife. Many parts of the hand board need to be processed on several surfaces, so it needs to be filled with gypsum and turned over for processing. Filling with gypsum saves the cost of manufacturing fixtures. After processing the product, remove the gypsum and clean it.

清理试装： 把CNC加工出来的结构手板件去除石膏、披锋。一些未加工到的就手工处理，比如一些直角未加工到的手工铲成直角，拆件加工的要拼接粘接起来，需要装配的试装是否有干涉。3D打印出来的工件也是需要手工清理、拼接、试装，因为在打印中会有支撑，撑住工件保证工件不变形，打印出来后就需要支撑。

Cleaning and trial assembly: Remove gypsum and sharp edges from the structural hand panels processed by CNC. Some unprocessed parts are manually processed, such as those that have not been processed into right angles by hand, which need to be spliced and bonded when disassembling and processing, and whether there is interference in the trial assembly that needs to be assembled. The 3D printed workpiece also requires manual cleaning, splicing, and trial assembly, as there will be support during printing to support the workpiece and ensure it does not deform. After printing, the support needs to be removed.

打磨抛光：  CNC加工和3D打印出来的结构手板件表面还是有刀纹不平整需要打磨抛光才光滑，光滑才可做后续的后处理喷漆、电镀、氧化等等。这一步也是需要的师傅打磨，要不会磨变形，产品无线条感，菱角的磨成R角或磨不到位，比如透明亚克力面罩CNC加工出来是磨砂半透的需要打磨师傅打磨抛光才达到透明，不的抛不透，或者透明了表面还有很多刀纹和划痕。

Polishing and polishing: The surface of structural hand panels processed by CNC and 3D printing still has uneven blade patterns. Polishing and polishing are necessary to achieve smoothness, and subsequent post-processing such as painting, electroplating, oxidation, etc. can only be carried out after being smooth. This step also requires a professional master to polish, in order to avoid deformation, the product has no stripe, and the diamond corners are ground to an R angle or cannot be polished in place. For example, if the transparent acrylic mask CNC is processed, it needs to be polished by a polishing master to achieve transparency. If it is not polished by an unprofessional master, or if it is transparent, there are still many knife lines and scratches on the surface.

表面处理： 把打磨好的手板上色或做其他处理。比如喷油氧化丝印镭雕，这一步是更关键的，设计和前面的加工制作有没有做好就看这一步了。外观颜色的搭配和产品的线条，做完后处理就马上可以体现。

Surface treatment: Color or perform other treatments on the polished hand board. For example, oil spray oxidation screen printing laser carving is the most crucial step, and whether the design and previous processing are done well depends on this step. The combination of exterior colors and product lines can be immediately reflected after processing.
